3D Scanner
A 3D scanner creates digital 3D models of real-world objects. It does this by projecting light (like structured light or laser) onto the object's surface. A sensor then measures how the light is distorted to calculate the object's 3D shape, creating a point cloud that forms the 3D model.
3D scanners are either contact or non-contact. Non-contact scanners, which are more common, are further divided into handheld and desktop types. These scanners are used in many fields, including manufacturing (reverse engineering and quality control), medicine (custom devices), archiving (preserving artifacts), and entertainment (creating visual effects for games and films).
Hair & Eye Friendly
For Human Scan
VCSEL + MEMES
Wireless 3D Scanner
Hair & Eye Friendly
For Human Scan
SHINING
EINSTAR 3D Scanner
．High Quality Data Up to 0.1mm
．Smooth Scanning Speed Up to 14 FPS
．Ideal for Dark or Shiny Surfaces, Hair & Outdoors
．Built-in RGB Color Camera
．User-Friendly Software Optimizes the point cloud
EINSTAR v1.2
Enhanced 3D Scanning Performance
The latest software update introduces True Scan Restoration algorithms, resulting in significantly improved data quality. Users can now obtain sharper details, clearer data resolution, and more vibrant texture mapping, regardless of the scanning environment. The EINSTAR v1.2 remains a cost-effective and portable solution that outperforms competitors in its price segment.
.webp)
High-Resolution 3D Data Acquisition
The SHINING EINSTAR 3D Scanner captures the point cloud data with a minimum point distance of 0.1 mm, enabling the creation of highly detailed 3D models.
High-Fidelity Color Data Acquisition
The integrated RGB camera captures high-resolution color information, ensuring accurate color representation in the resulting 3D model.
Enhanced Material Compatibility
The use of an infrared VCSEL light source enables reliable 3D scanning of materials with high reflectivity and low light absorptivity, such as black and shiny surfaces.
Comprehensive Software Suite for 3D Data Processing
The software includes a data quality indicator for optimizing point cloud acquisition, supports multiple output formats (OBJ, STL, PLY, P3, 3MF), and offers seamless integration with various CAD software packages and 3D printers. A data rewind function minimizes data loss in case of scanning errors.
Seamless 3D Data Management and Collaboration
The SHINING 3D digital cloud platform provides a secure and efficient way to share and manage your 3D scan data. Collaborate with colleagues and clients, and showcase your innovative designs with ease.
Optimized 3D Scanning Workflow
The system boasts a high scanning speed of up to 14 FPS, simplified setup and operation, automatic alignment capabilities, and intelligent algorithms for enhanced tracking performance and data accuracy.
Reliable Outdoor Scanning
Capture accurate 3D data even in challenging outdoor environments.
Projector-less Design for Enhanced User Safety & Comfort
The absence of projector light eliminates eye strain and ensures a comfortable scanning experience, particularly for full-body scans. The integrated "Hair Mode" function optimizes data acquisition for accurate hair representation, resulting in more complete and detailed 3D models.
3D Scan Mode | Structured Light Scan |
Light Source | VCSEL |
Point Distance | 0.1~3mm |
3D Scan Speed | Up to 14 FPS |
Working Distance | 160 ~ 1400mm (Optimal Working Distance: 400mm) |
Align Mode | Feature / Texture / Markers / Hybrid |
Outdoor 3D Scanning | Support |
Product Dimension | 220*46*55mm |
Product Weight | 500g (1.1lbs) |
%20EINSTAR%20VEGA%20Wireless%203D%20Scanner.png)
SHINING
EINSTAR VEGA 3D Scanner
．2 Scanning Technologies in 1: VCSEL + MEMS
．Wireless Scanning, Sharing & Screen Casting
．Built-in 48MP RGB Texture Camera
．Extensive Storage: 32GB eMMC + 512GB SSD
Smart 3D Scanning Terminal with Mobile Computing
Optimized Hardware
8-core CPU, 2.4GHz
Independent 512GB SSD
32GB RAM
AI-Powered
Scan, process, and generate 3D models directly on the device.
High-Capacity Scanning Performance
Up to 18,000 Frames
Advanced Algorithms:
- Auto Exposure - Adaptive Scanning
- Data Optimization - Real-Time Alignment
Two 3D Scanning Technologies in One
VCSEL Projector
For Long Range Scanning
Smooth Scanning under
Unlimited Environment
MEMS Projector
For Short Range Scanning
Stable Scanning
for High-Detail Data
Coverage from Small to Large Objects
Strong Environment Lighting Adaptability
Work perfectly in both sunlight and darkness.
Sunlight
Scans flawlessly under direct sunlight up to 100,000 lux.
Darkness
Real-time white balance and fill light deliver true colors, even at night.
Wireless 3D Scanning Solution
Wireless Scanning
Built-in WiFi 6 and wireless casting for ultimate flexibility
Wireless Screen Casting
Tap the screen, scan like shooting a video, and share effortlessly
Wireless Sharing
Secure personal cloud space for instant sharing
Pro-level Features Accelerate Work Efficiency
12mm Markers Alignment
Same Coverage
12mm Markers = 40% 6mm Markers
Real-time Data Alignment Correction
The scanning rewind function enables users to rectify alignment errors that may occur during the 3D scanning process, preventing the need to restart the scan and preserving valuable data.
Intelligent Base Plane Detection
This feature intelligently identifies and removes base planes (e.g., tables, turntables, ground) from the scan data both before and during the scanning process, resulting in cleaner 3D models without manual post-processing.
More Alignment Modes
Beyond Standard Material
48MP RGB Camera for Lifelike Colors that Never Fade
.webp){kind=tracking}
.webp){kind=tracking}
Best Partner for Beginners
One-Click Start
One-Click Processing
Coordinate System Adjustment
Model Measurement
SHINING 3D Cloud
3D Scan Mode | HD Mode / Fast Mode |
Light Source | VCSEL / MEMS |
Point Distance | (HD Mode) 0.05~3mm / (Fast Mode) 0.5~10mm |
3D Scan Speed | (HD Mode) Up to 15 FPS / (Fast Mode) Up to 20 FPS |
Working Distance | (HD Mode) 100~350mm / (Fast Mode) 350~1500mm |
Align Mode | Feature / Texture / Markers / Hybrid |
Outdoor 3D Scanning | Support |
Product Dimension | 180*95*26.5mm |
Product Weight | 535g (1.18lbs) |
.jpg)
3DMakerPro
MOLE 3D Scanner
．0.05mm Accuracy
．0.1mm Resolution
．Multispectral Technology
．Dedicated Mobile Scanning App
(requires optional CONNECT)
A Powerful Combination of Hardware & Software
3DMakerPro MOLE 3D Scanner boasts high precision (up to 0.05mm accuracy) for capturing fine details, a fast-scanning speed (up to 10 FPS), and a convenient 200x100mm single capture range. The resulting 3D models are exported in industry-standard OBJ, STL, and PLY formats, ready for immediate use in various applications or further creative manipulation.
Up to 0.05mm Accuracy
0.1mm
High-Definition Resolution
Multispectral Technology
No-marker Scanning
Safe Facial Scanning
MOLE uses a harmless near-infrared (NIR) light source, ensuring a safe and comfortable scanning experience.
High-Precision 3D Scanning
MOLE's scanning technology achieves an accuracy of up to 0.05mm and a point distance of 0.1mm, resulting in exceptionally precise and detailed 3D models suitable for demanding applications.
0.05mm Accuracy
0.1mm Resolution
MOLE's high-precision and high-resolution lenses capture intricate details and accurately recreate the size of scanned objects.
Ultra-Clear Texture Mode
Accurately reproduce the color and texture of your scanned objects (e.g., your sneakers) with MOLE's high-fidelity texture mapping.
Tips: Color models require the color kit, included in the luxury combo.
Overcoming the Challenges of Black Object Scanning
MOLE's near-infrared (NIR) light source provides excellent optical compatibility, resulting in clear and accurate scans of objects of all colors, including black, where traditional methods often struggle.
High Scan Success Rate
MOLE incorporates optical anti-shake modules and sophisticated visual tracking algorithms to minimize motion blur and ensure the capture of complete and accurate 3D models in every scan.
Visual Tracking Technology
MOLE employs advanced visual tracking technology and a self-developed AI algorithm to perform markerless scanning. This eliminates the need for time-consuming marker placement and significantly reduces overall scanning time.
Optical Anti-shake Modules
MOLE's optical anti-shake modules deliver smooth, stable scanning at high frame rates, minimizing distortion and ensuring accurate results, even when handheld.
Optimized for Comfort and Extended Use
MOLE's compact and ergonomic design minimizes user fatigue during extended scanning sessions, whether handheld or using a turntable. An integrated, quiet-running cooling fan effectively manages internal temperatures, allowing for prolonged operation without performance degradation.
Enhanced Portability
with 3DMakerPro CONNECT
The 3DMakerPro CONNECT accessory transforms MOLE into a portable 3D scanning solution, enabling stable and reliable scans in various locations.
Tips: CONNECT requires a power bank with a 12V PD 22.5W type-C interface.
Powerful Graphics Chip
The 3DMakerPro CONNECT's powerful image processing chip delivers high-quality scans, even in challenging outdoor conditions, by seamlessly connecting MOLE to your smartphone.
Simple Setup, Reliable Performance
3DMakerPro CONNECT ensures a quick and easy connection between your MOLE, tripod, phone, and power supply, for reliable scanning every time.
Light Source | Near-Infrared (NIR) |
3D Scan Speed | Up to 10 FPS |
Working Distance | 150 ~ 400 mm |
Single Capture Range | 200 x 100 mm |
Typical Object Sizes | 15 ~ 1500 mm |
Product Dimension | 141 x 80 x 80 mm |
Product Weight | 390g |
